Application: Ductless (mini-split) systems
This product is designed to automatically pump condensate produced by
ductless (mini-split) systems. It provides lift up to 35' (10m) once the level
of condensate in the tank reaches a specified level.
ClearVueTM Mini is the ideal condensate pump for ductless (mini-split)
systems. Its compact size helps it fit almost anywhere including inside many
wall cassette units and inside line set cover systems. And the whisper quiet
operation makes it easy to live with even when the pump is installed near
The variable lift in ClearVueTM Mini assures that the pump is running only
as fast as is needed to lift the condensate water to the height needed.
DiversiTech's patent pending Floatless Sensor eliminates many of the
mechanical problems associated with conventional condensate pumps.
FEATURES & BENEFITS
ClearVue™ Mini is compact only 31/2" x 2" x 3". It fits almost anywhere including inside a line set cover, inside the wall cassette unit(on some cassette models), and easily to installs in ceiling or behind a wall. ClearVue™ Mini features suction lift of up to 6 feet.
ClearVue™ Mini determines how fast condensate is entering the tank and adjusts its speed and lift to match the conditions and keep the tank clear
Electromechanical float switches used in conventional condensate pumps are prone to mechanical failure including debris fouling, sunken floats, and misalignment. ClearVue Mini's Floatless Sensor™ eliminates the problems associated with conventional condensate pumps. No float, no problem.
ClearVue™ Mini is nearly inaudible. The sound rating is significantly less than 20 dB. You literally can hardly hear the pump run. This quiet operation allows maximum installation flexibility, as you can place the pump right in the room with the wall cassette.
ClearVue™ Mini can be powered with any voltage from 120 to 240V, 50 or 60 Hz. With one product suitable for multiple voltages, there is no need to stock separate SKUs for different voltages.
Shuts down the compressor in case of a clogged line. Prevents damage to equipment or environment.
The clear tank feature of ClearVue™ Mini allows the user to see the activities inside making troubleshooting more accurate and much faster.
ClearVue™ Mini features an aluminum housing that is built to last. This aluminum protects the pump from physical damage, and helps contribute to the super quiet operation of the pump.
Tank can be located away from pump if needed, more flexible installation Small tank fits inside most indoor cassettes.
The molded rubber mounting pad can be used to mount ClearVue™ Mini to a vertical or horizontal surface; or to copper refrigerant lines with cable ties. The rubber pad decreases sound and vibration, contributing to a very quiet pump.
ClearVue™ Mini has a dependable, extended 2 year warranty.
ClearVue™ Mini features three LED indicator lights: Ready, Pumping, and Alarm. The LED lights tell you what mode the pump is in at any given time.
|Rated Voltage/Frequency||120/240 Volts 50/60 Hz|
|Rated Current Draw||1.0 Amps|
|AC Cable||3 Cond. Jacketed Flex. PVC|
|Flow Rate at Zero Head||500mL/16.91oz/min, 8 gallons/hr|
|Maximum Rated Inlet Flow Rate||100mL/3.38oz/min|
|Temperature Rating||Continuous duty 60°C/140°F Max|
|Safety Switch||5A at 230VAC|
|Product Dimensions||8.6cm x 4cm x 4.7cm (3.38" x 1.57" x 1.84")|
|Product Weight||.5kg/1.1 lbs.|
|Inlet Height from Base||1.3cm/0.5"|
|Wiring Color References||Brown - Hot 120v/hot 240v, Blue - Neutral 120v/hot 240v, Green/yellow - Ground|
