Diversitech ClearVue Condensate Pump, 0-22ft. lift, 120V - IQP-120
The new ClearVue™ condensate pump from DiversiTech is unlike any other pump available.
ClearVue™ features variable speed and lift and selfcleaning technology which makes
ClearVue™ the smartest condensate pump on the market. ClearVue™ has the ability to "think" and adapt to changing conditions. It's not just off or on like a regular pump.
ClearVue™ senses the amount of condensate water in the tank and the rate of inflow and
adjusts its speed and lift to match the conditions and keep the tank clear. ClearVue™ starts
pumping slowly and only accelerates if needed. And since it pumps slowly, ClearVue™ is
super quiet and easy to live with.
FEATURES & BENEFITS:
ClearVue™ senses how fast the condensate is entering the tank and
adjusts its speed and lift to keep the tank clear. This helps ClearVue
operate at the proper speed and makes the pump work quietly.
Electromechanical float switches used in conventional condensate
pumps are prone to mechanical failure including debris fouling, sunken
floats, and misalignment. ClearVue’s Floatless Sensor™ eliminates the
problems associated with conventional condensate pumps. No float, no
ClearVue™ condensate pump features a unique, selfcleaning mode to
maintain and keep drain lines clear.
The clear tank feature of ClearVue™ allows the user to see the activities
inside making troubleshooting more accurate and much faster.
ClearVue™ contain two stainless steel hanging tabs that offer many
installation options. The tabs are sturdy and durable, lasting longer than
standard plastic mounts.
ClearVue™ features four LED indicator lights: Ready, Pumping,
Cleaning, and Alarm. The LED lights tell you what mode the pump is in
at any given time.
ClearVue™ includes specially designed rubber feet that dampen
vibration and noise making ClearVue™ quiet and easy to live with.
Removable duckbill check valve resists corrosion and wear and is self
An innovative packaging design with a clear front shows the pump and
highlights its unique features. Several ClearVue™ pumps may also be
stacked together to create a powerful visual display.
Need to drain the tank quickly? Simply push the DRAIN button and
ClearVue™ removes all the water in the tank fast.
ClearVue™ has a dependable, extended 2 year warranty.
|Maximum Condensate||Continuous duty 160F°|
|Temperatures||Maximum inlet temperature 160F°|
|Temperatures||Not suitable for contact with steam or gasses that exceed 160F°|
|Rated Voltage||120 VAC / 60Hz|
|Rated Current Draw||1.9 Amps (120VAC)|
|Input Type||USA 3-prong molded plug (120VAC)|
|Maximum Lift Height||Variable, 0 to 22 feet|
|Flow Rate @ Zero Head||1.6 gallons per minute|
|Dimensions||11.8" x 5.9" x 6.7"|
|Inlet Height from Base||4.4"|
|Tank Capacity||1/2 gallon|
|Stainless Steel Hang Tabs|
|4' Remote Shutoff Leads w/insulated terminals|
|Polyethelene inlet covers (3)|
|Wiring Color References||120V Black - Live/Hot White - Neutral Green - Ground (All installations must conform to NEC requirements)|
